High Performance Electric Submersible Pump Hydraulic Packer For Well Completion

Minimum Order Quantity :	1 set	Price :	USD 1-10000/set
Packaging Details :	Pollywood	Delivery Time :	30-50 days
Payment Terms :	L/C, T/T, D/P	Supply Ability :	10 set/month

Place of Origin:	China	Brand Name:	ZZ TOP OIL TOOLS
Certification:	ISO, API	Model Number:	HP ESP Packer

Detail Information
Product:	HP ESP Packer	Application:	Oil & Gas Well Completion Operation
Usage:	Pumping The Formation Fluids To The Surface	Size:	9 5/8” 40-47# X
Working Pressure:	5000 Psi	Connection:	IF, EUE , CAS
Working Condition:	Oil & Gas & H2S Service	Working Temperature:	Up To 300 OF
Highlight:	Hydraulic Packer Electric Submersible Pump , High Performance Electric Submersible Pump , Well Completion Electric Submersible Pump

Product Description

High Performance Electric Submersible Pump Hydraulic Packer For Well Completion

The High Performance Electric Submersible Pump Hydraulic Packer is the HP ESP Packer used with a completion that requires an electric submersible pump below thepacker to assist in pumping the formation fluids to the surface. The high performance ESP packer is a hydraulic set, shear release packer designed to facilitate the use of an electrical submersible pump (ESP), multiple production strings, and/or control line feedthroughs by allowing for multiple offset bores through the packer. This packer is rated for 300°F and 5,000 psi.

Technical parameter of 9 5/8" HP ESP Packer

Product Name	HP ESP Hydraulic Packer
Product Type	Retrievable Packer
Product Charateristics	Slip Anchor
Ser ives Provided	NACE
Metallic Material	13Cr-L 80(Flow Wetted) , AISI4140or Equal Alloy Steel
Non-Metallic Material	HNBR Element Material, FKM O-ring
Maximum OD	8.450	inch	214.63	mm
Primary String ID	2.920	inch	74.17	mm
Second String ID	1.610	inch	40.89	mm
Overall length	56.600	inch	1437.64	mm
Pressure Rating	5,000	PSI	35.0	MPa
Burst Pressure/Cylinder	5,905	PSI	40.7	MPa
Collapse Pressure/Cylinder	5,746	PSI	39.6	MPa
Tensile Rating	50,000	lbs	22.6	ton
Compression Rating	200,000	lbs	90.7	ton
Maximum Temperature Rating	300	oF	148.8	C

High Performance Electric Submersible Pump Hydraulic Packer For Well Completion 0
